KR 1000 titan
The KR 1000 titan is our powerful robot for heavy loads. The six-axis robot moves very heavy parts and components safely and precisely, even over long distances.
The KR 1000 titan is the first six-axis robot with an open kinematic system and an unparalleled payload capacity. It masters the handling of heavy loads over distances of up to 6.5 meters precisely and quickly. Engine blocks, stones, glass, steel beams, components for ships and aircraft, marble blocks, precast concrete parts – all of these heavy loads are no problem for the KR 1000 titan. For special areas of application, we offer the Foundry variant with the best reach/payload ratio or the version as a palletizing robot for heavy loads of up to 1.3 tonnes.
KR 1000 titan (6 axes) - technical data

					Robots

				Total load
				Maximum reach
				Version environment
				Downloads

						KR 1000 L750 titan

					Total load
						750 kg
					Maximum reach
						3601 mm
					Version environment
						Standard
					Downloads

					- Total load 750 kg
- Maximum reach 3601 mm
- Construction type Standard
- Version environment Standard
- Mounting positions Floor
- Protection class IP 65
- Downloads Download Center
- Controller
						KR 1000 L750 titan F

					Total load
						750 kg
					Maximum reach
						3601 mm
					Version environment
						Foundry
					Downloads

					- Total load 750 kg
- Maximum reach 3601 mm
- Construction type Standard
- Version environment Foundry
- Mounting positions Floor
- Protection class IP 65, IP 67
- Downloads Download Center
- Controller
						KR 1000 L950 titan PA

					Total load
						950 kg
					Maximum reach
						3601 mm
					Version environment
						Standard
					Downloads

					- Total load 950 kg
- Maximum reach 3601 mm
- Construction type Palletizing robot
- Version environment Standard
- Mounting positions Floor
- Protection class IP 65
- Downloads Download Center
- Controller
						KR 1000 titan

					Total load
						1000 kg
					Maximum reach
						3202 mm
					Version environment
						Standard
					Downloads

					- Total load 1000 kg
- Maximum reach 3202 mm
- Construction type Standard
- Version environment Standard
- Mounting positions Floor
- Protection class IP 65
- Downloads Download Center
- Controller
						KR 1000 titan F

					Total load
						1000 kg
					Maximum reach
						3202 mm
					Version environment
						Foundry
					Downloads

					- Total load 1000 kg
- Maximum reach 3202 mm
- Construction type Standard
- Version environment Foundry
- Mounting positions Floor
- Protection class IP 65, IP 67
- Downloads Download Center
- Controller
						KR 1000 1300 titan PA

					Total load
						1300 kg
					Maximum reach
						3202 mm
					Version environment
						Standard
					Downloads

					- Total load 1300 kg
- Maximum reach 3202 mm
- Construction type Palletizing robot
- Version environment Standard
- Mounting positions Floor
- Protection class IP 65
- Downloads Download Center
- Controller
						KR 1000 1300 titan PA-F

					Total load
						1300 kg
					Maximum reach
						3202 mm
					Version environment
						Foundry
					Downloads

					- Total load 1300 kg
- Maximum reach 3202 mm
- Construction type Palletizing robot
- Version environment Foundry
- Mounting positions Floor
- Protection class IP 65, IP 67
- Downloads Download Center
- Controller
